Tilting Arbour Machine

Get a Price/Quote

MOQ : 1 , , Unit

Tilting Arbour Machine Specification

Product Type
Tilting Arbour Machine

Machine Type
Woodworking Cutting Machine

Machine Style
Table Saw

Capacity
Up to 75 mm cutting depth

Voltage
220-240 V / 415 V (as per requirement)

Power
3 HP 5 HP motor

Automation
Semi Automatic

Motor
Copper wound induction motor

Speed
2800 RPM

Dimension (L*W*H)
Approx. 1800 mm x 900 mm x 1050 mm

Weight
320 kg (approx.)

Color
Blue & White

Operation
Manual feed with tilting facility

Maximum Cutting Height at 90°
75 mm

Arbour Tilt Range
0 to 45 Degrees

Table Material
Heavy-duty Cast Iron

Dust Collection Port Diameter
100 mm

Suitable for
Timber, Plywood, MDF, Laminates cutting

Extension Table
Provided

Table Size
1220 mm x 900 mm

Saw Guard
Transparent polycarbonate

Blade Bore
30 mm

Maximum Cutting Height at 45°
50 mm

Rip Fence
Adjustable precision fence

Blade Diameter
300 mm

Tilting Arbour Machine Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
3-15 Days

About Tilting Arbour Machine

Tilting Arbour Machine is a versatile woodworking tool used for making precise and angled cuts in wood. It has a tilting arbor that can be adjusted to different angles, allowing the blade to cut at a specific bevel or angle. The machine also has a powerful motor, a durable table, and an adjustable fence for accurate and smooth cutting operations. With its tilting capabilities, it can make precise cuts for projects such as furniture-making, cabinetry, and other woodworking tasks. Tilting Arbour Machine is a valuable addition to any professional or DIY woodworking workshop.

Precise Tilting for Versatile Cuts

This machine enables precise angled cuts ranging from 0 to 45 degrees, making it ideal for complex joinery and bevel applications. The tilting arbour feature ensures accuracy and easy operation while cutting various wood-based materials.

Sturdy Cast Iron Table Design

The heavy-duty cast iron table supports large panels and provides unmatched stability during operation. Its 1220 mm x 900 mm dimensions allow for comfortable material handling, reducing vibrations and enhancing cutting precision.

Efficient Dust Collection and Safety

A 100 mm diameter dust collection port keeps your workspace cleaner by effectively removing sawdust. The transparent polycarbonate saw guard provides added safety by allowing clear visibility of the blade during cutting.

FAQs of Tilting Arbour Machine:

Q: How does the tilting arbour mechanism operate on this machine?

A: The tilting arbour mechanism allows you to adjust the blade angle smoothly between 0 and 45 degrees using manual controls, facilitating beveled and angled cuts as required for woodworking projects.

Q: What materials can I cut using this tilting arbour table saw?

A: You can efficiently cut timber, plywood, MDF, and laminates with this saw, making it suitable for a range of woodworking tasks including furniture, cabinetry, and construction work.

Q: When should the adjustable rip fence be used?

A: The adjustable precision rip fence is used whenever straight, parallel cuts are needed. Its secure locking mechanism ensures consistent measurements and supports repetitive cutting tasks.

Q: Where should the dust collection port be connected for optimal performance?

A: Connect the 100 mm diameter dust collection port to a suitable industrial vacuum or dust extraction system. This maximizes sawdust removal for a cleaner and healthier workspace.

Q: What is the maximum cutting capacity of this table saw at different angles?

A: The maximum cutting height is 75 mm when the blade is at 90, and 50 mm when tilted to 45, allowing for deep and angled cuts for various woodworking applications.

Q: How does the extension table benefit users during operation?

A: The provided extension table offers additional workspace for handling larger panels, improving stability, workflow efficiency, and safety during cutting operations.
